Xilinx® Kintex7® FPGA and 10 Gbit Ethernet Marvell Alaska X 88X3310P PHY on a single board. The FPGA’s MGT lines support rates up to 12.5 Gbit

The module is equipped with 1 GByte of DDR3L SDRAM and 32 MByte of Flash memory as a storage for configuration

Six GTX multi-gigabit transceivers and three full FPGA I/O banks (in total 150 single-ended I/O or up to 72 differential pairs)

With configurable IO voltage are available via two high-speed, high-pin-count, board-to-board connectors

The user to attach literally only connectors and a single DC power supply

10 Gbit to 10 Mbit data rates
Compliant with NBASE-T 2.5 G and 5 G
master control Kintex 7 – XC7K160T-2FFG676I
100 m reach on Cat6a for 10 G
6 x GTX Transceivers
150 single-ended I/O
1GB DDR3L memory (32b x 1600Mt/s)
3.3V single voltage power supply
high-density board-to-board connectors
