Processor Intel ® Celeron ® J1900,2mb, cache, 4cores, 4threads, 2.00GHz, tdp10w, 22nm
Memory Onboard 4gbddr3l1333mhz memory
Support windows7/linux and other operating systems
BIOS AMI BIOS supports modifying boot logo
Two RJ-45 standard Gigabit IEEE802.3af (12.95w) Poe ports
Usbi 3*usb2.0
Usbii 1*usb3.0
Comi 2*3-wire RS-232, sharing one standard DB-9 seat
Comii 1*rs-485
Power input I 1*dc in 24V, used for power supply of the whole machine, 24v/12a
HDMI 1* standard HDMI interface, with a maximum supported resolution of 1920*1200
Gpo: the maximum output current of each circuit is 500mA, and the output voltage is dc9-30v (depending on the voltage of the power supply terminal)
Camera power supply 2*dc out 12V
Storage: msata hard disk interface, default 64GB hard disk sata2.0 interface
Watchdog WDT Support 256 levels (0~255), programmable

no fan, integrated heat dissipation design
complete functions and compact size
2*dc in 24V DC power supply, supporting power reverse connection protection
support HDMI HD mode, with a maximum resolution of 1920*1200
2*poe, providing +dc 48V power supply output, with total power not exceeding 50W
featured one key backup and one key recovery buttons
4* light source output control terminal, 4* camera trigger terminal1
